PIR153-240AC-00T

реле времени могофункц. 3C/O. 240VAC. Set: R15+COM3

Дополнительная информация тут.

Contact data
Contact material	AgNi
Max. load AC1	2 500 VA
Max. switching voltage AC	440 V
Max. switching voltage DC	250 V
Number and type of contacts	2 C/O, 3 C/O
Rated load AC1	10 A / 250 V AC
Dielectric strength:
contact clearance	1 500 V AC
input - output	2 500 V AC
pole - pole	2 500 V AC
Input control circuit
Rated voltage 50/60 Hz AC	24 - 240 V
Rated voltage DC	12 - 220 V
Insulation
Insulation rated voltage	250 V A
Time module data
Functions	E, E(S), Wu, Wu(S), Bp, Bp(S), Bi, Bi(S), R, Ws, Wa, Es
Min. time of pulse duration	100 ms
Time intervals	1s … 10 d
Общие данные
Ambient temperature operating	-40...+55 oC
